Spot Lights from the Chinese manufacturer OPT Machine Vision are available in different versions:
Group photo series
Selection guide
The lights are each available in four colour versions: -R, -W, -G, -B. For further details refer to the series catalogue.
| Designation | Output R | Output WGB | Controller |
|---|---|---|---|
| OPT-PIG0803 | 0.7A/1.8W | 0.7A/2.3W | OPT-DPA2005E |
Group photo series
Selection guide
The lights are each available in four colour versions: -R, -W, -G, -B. For further details refer to the series catalogue.
| Designation | Output W | Output R | Output G | Output B | Controller |
|---|---|---|---|---|---|
| OPT-LDS50 | 1V / 3.2W | 1V / 2.7W | 1V / 3.75W | 1V / 3.3W | OPT-DPA2005E |
Group photo series
Selection guide
For further details refer to the series catalogue.
Group photo series
Selection guide
The lights are each available in four colour versions: -R, -W, -G, -B. For further details refer to the series catalogue.
| Designation | Output W | Output R | Output G | Output B | emitt. surf. diameter [⌀ mm] | Working Distance [mm] | Controller | Opt. accessory |
|---|---|---|---|---|---|---|---|---|
| OPT-PL23 | 1A / 3.2W | 1A / 2.7W | 1A / 3.75W | 1A / 3.3W | 23 | 45–90 | OPT-DPA2005E | OPT-PPL23 |
| OPT-PL35 | 1A / 3.2W | 1A / 2.7W | 1A / 3.75W | 1A / 3.3W | 35 | 45–90 | OPT-DPA2005E | OPT-PPL35 |
| OPT-PL70 | 1A / 3.2W | 1A / 2.7W | 1A / 3.75W | 1A / 3.3W | 70 | 100–200 | OPT-DPA2005E | OPT-PPL70 |
| OPT-PL100 | 1A / 3.2W | 1A / 2.7W | 1A / 3.75W | 1A / 3.3W | 100 | 150–300 | OPT-DPA2005E | OPT-PPL100 |
