Machine Vision Cables

Eureca is the german representative of Electronic Links International Inc., which designs, manufactures, exports, and sells electrical connectors and cable assemblies both in copper and fiber optics, as well as other electrical components.

Available are especially cables for machine vision applications in different lengths and connector configurations.

USB3.0 Cables

• A Plug to Micro-B With Screws
• A Plug to A Plug
• A Plug to B Plug
• A Plug to Micro B Without Screws
• Active Cable Micro-B Plug to A Plug
• A Plug to Angled B Plug With Screws
• A Plug to Angled Micro B Plug With Screws
• A Plug to B Plug With Screws
• Micro B Plug With Screws to A Plug With Screws

The cables are available in lengths of 15 cm up to 7 m (passive cable) or 15 m (active cable). Further Details on the technical data can be found in the combined data sheet.

RJ45 GigE Cable

• Plug to Plug with Screws
• Latch Plug with Screws to Angled Plug with Screws
• Angled Plug with Screws to Plug
• Latch Plug with Screws to Latch Plug with Screws
• Plug to Plug
• Plug to Vertical Plug with Screws
• Latch Plug with Screws to Vertical Plug with Screws

The cables are available in lengths of 15 cm up to 90 m. FurtherDetails on the technical data can be found in the combined data sheet.

1394b Cable

• 9 Pin to 9 Pin Plug with Screws
• 9 Pin to 9 Pin Up Angle with Screws
• 9 Pin to 9 Pin Down Angle with Screws
• 6 Pin to 9 Pin Bilingual Plug

The cables are available in lengths of 15 cm up to 10 m (passive cable) or 40 m (active cable).

Camera-Link Cable

• MDR to SDR
• MDR to MDR

The cables are available in lengths of 30 cm up to 7 m. Further Details on the technical data can be found in the combined data sheet.

CoaXPress

• Channel CXP BNC to Din1.0/2.3
• Channel CXP BNC to Din1.0/2.3, High Flex
• 4 Channel CXP DIN1.0/2.3 TO BNC

The cables are available in lengths of 20 cm up to 50 m. Further Details on the technical data can be found in the combined data sheet.

CCD Industrial Cables

• Trigger Cable HR10A 12P Female-Adapter Cable
• HR10A 06P Female-Adapter Cable
• Trigger Cable HR10A 06P Female-Strip&Tin-xm-Flex
• Trigger Cable HR25 08P Male-Cut
• Trigger Cable HR10A 06P Female-Strip&Tin-xm-STD

The cables are available in lengths of 30 cm up to 10 m.

A compact overview of the available cable types (also other connection types) can be found here.
