| Description | Bumblebee X 5GigE by Teledyne FLIR |
| Articlenumber (Eureca): | 02.17.0403 |
| Origin: | Canada |
| Manufacturer: | FLIR |
| Frame Rate | 16 fps |
| Megapixel | 3 MP |
| Chroma | Color |
| Sensor | Sony IMX265 |
| Sensor type | CMOS |
| Readout | Global shutter |
| Min. free working distance [m] | 0.5–20 m |
| Sensor format | 1/1.8 ″ |
| Pixel size | 3.45 µm |
| Lens mount | ¼”-20, M4 |
| Interface | Gigabit Ethernet 5 Gbps / 2.5 Gbps / 1 Gbps |
| Power supply | Power over Ethernet (PoE); or 12–24 V via GPIO |
| Dimension [mm] | 304 × 64 × 48 |
| Weight | 905 g |
| Compliance | CE, FCC, RoHS |
| Machine Vision Standard | GigE Vision v2.0 |
| Warranty | 3 years |
| Operating Humidity | 20–80 % |
| Operating Temperature | −10–50 °C |
| Storage Humidity | 20–95 % |
| Storage Temperature | −30–60 °C |
| Image Processing | On-board disparity processing |
| I/O (non-isolated) | 3 bi-directional |
| System Port | 5Gigabit Ethernet Port |
Bumblebee® X is a comprehensive, industrial-grade (IP67) stereo image processing solution with onboard processing for building successful warehouse automation, robot guidance and logistics systems.
Features:
For this camera model Eureca offers many accessories as for example:
Our technical team would be happy to assist you in selecting the most suitable components. Please contact us!
Documents for download:
Datasheet
Technical Reference
Getting Started
Technical Drawings
More pictures of the product:
Changes to the specifications by the manufacturer are possible without prior notice. Please contact us if needed or interested. We also advise you on the suitability of the product for a particular application and provide you with an individual price quote.
Last update: 03.14.2025
