Starterkit-e9u-LSMD

DescriptionStarter kit for line scan camera boards
Articlenumber (Eureca):02.29.0004
Origin: Deutschland
EAN0675051081492
USB-Powered
Optional External Power Supply

Sample picture

To the product series

The starter set is based on a Raspberry single-board computer. To start up the camera modules (please order separately!), only a monitor with an HDMI connection, mouse and keyboard are required.

The set consists of:

  • Raspberry Pi3 Model B Plus with 1.4 GHz QuadCore CPU 2.4 GHz, 1 GB Ram, 4 USB 2.0 Ports, WLAN and Bluetooth 4.2 BLE
  • attached heat sink in aluminum housing
  • Plug-in power supply 220V AC Euro plug
  • Supplied microSD card with pre-installed operating system and GUI interface (GUI: Grafical User Interface) for the separately selected camera module

Please use our online shop to place an order!






Documents for download:

Flyer of the e9u-LSMD line scan camera modules from Eureca (german)
Flyer of the e9u-LSMD line scan camera modules from Eureca (english)



Other versions of the article and matching products:


Changes to the specifications by the manufacturer are possible without prior notice. Please contact us if needed or interested. We also advise you on the suitability of the product for a particular application and provide you with an individual price quote.

Last update: 12.06.2021
