| Articlenumber (Eureca): | 01.04.0107 |
| Manufacturer: | Toshiba |
| Colour version | monochrome |
| Pixel number | 3648 |
| Pixel size x | 8 µm |
| Pixel size y | 200 µm |
| Sensitivity (V/lx･s) (B/W) | 160 |
| Dynamic range | 300:1 |
| Maximum Data Rate monochrome [MHz] | 1 MHz |
| Supply Voltages | 4 V |
| Application scope | Barcode readers |
| Package | 22pin CERDIP |
| Linewidth [mm] | 29.20 mm |
| Features | 3V single power supply voltage / Electronic shutter (ICG) function / Sample-and-hold circuit |
Rear view of the sensor (sample picture)
Other versions of the article and matching products:
Changes to the specifications by the manufacturer are possible without prior notice. Please contact us if needed or interested. We also advise you on the suitability of the product for a particular application and provide you with an individual price quote.
Last update: 06.19.2023
