Description | Xenon Emerald Lens by Schneider Kreuznach |
Articlenumber (Eureca): | 06.05.0282 |
Origin: | Germany |
Manufacturer: | Schneider Kreuznach |
Designation | EMERALD 5.6/135 V48 |
Model Series | EMERALD |
Type | standard |
Manufacturer ID | 1104199 |
Mount | V48-Mount |
Focal length | 135 mm |
Aperture | 5.6–22 |
max. Sensor Format | 90 mm |
max. Angle | 37 ° |
Magnification | −0.5 – 0 × |
Min. free working distance [mm] | 379–∞ mm |
Filter thread [mm] | M49 × 0.75 |
Dimension [mm] | 55 × 63 |
This V48-mount lens is designed for large sensors up to 90 mm diagonal/length. It is characterized by an excellent imaging performance in a wide working distance range from 0.35 m to infinity. With optional V48 extension tubes and adapters it can be mounted to all common camera mounts. The robust mechanics and a special focus adjustment and locking mechanism ensure maximum mechanical stability even in harsh environments.
Key features:
Applications:
For full details and specifications, please refer to the data sheet linked below.
Documents for download:
Other versions of the article and matching products:
Changes to the specifications by the manufacturer are possible without prior notice. Please contact us if needed or interested. We also advise you on the suitability of the product for a particular application and provide you with an individual price quote.
Last update: 11.16.2022
