TOURMALINE-4.0-45-C

DescriptionCompact 1.3" AS Lens by Schneider Kreuznach
Articlenumber (Eureca):06.05.0279
Origin: Germany
Manufacturer: Schneider Kreuznach
DesignationTOURMALINE 4.0/45 C
Old DesignationXenoplan 4.0/45
Model SeriesTOURMALINE
Typestandard
Manufacturer ID1101715
MountC Mount
Focal length45 mm
Aperture4–22
max. sensor size1.3" (24 mm)
max. Angle29 °
Magnification−0.5 – 0 ×
Min. free working distance [mm]120–∞ mm
Filter thread [mm]M30.5 × 0.5
Dimension [mm]34 × 51.6
Weight78 g

To the product series

This high-resolution 1.3-inch lens is compact and robust, making it ideal for demanding imaging applications, even in harsh environments. The large magnification range combined with excellent resolution and low distortion results in excellent imaging results in many different imaging applications.

Key features:

  • Compact and robust design
  • Image circle 24 mm
  • Distortion <0.08 %
  • Magnification range inf. −0.5×



Applications:

  • Machine Vision
  • AOI (Automated Optical Inspection)
  • 3D and 2D measurement
  • Traffic and Surveillance



For full details and specifications, please refer to the data sheet linked below.






Documents for download:

Datasheet of the lens



Other versions of the article and matching products:


Changes to the specifications by the manufacturer are possible without prior notice. Please contact us if needed or interested. We also advise you on the suitability of the product for a particular application and provide you with an individual price quote.

Last update: 10.18.2023
