| Articlenumber (Eureca): | 01.04.0100 |
| Manufacturer: | Toshiba |
| Colour version | monochrome |
| Pixel number | 2048 |
| Pixel size x | 14 µm |
| Pixel size y | 200 µm |
| Sensitivity (V/lx･s) (B/W) | 80 |
| Dynamic range | 400:1 |
| Maximum Data Rate monochrome [MHz] | N/A MHz |
| Supply Voltages | 5 V |
| Package | 22 pin CERDIP |
| Linewidth [mm] | 28.70 mm |
| Remark | with UV coating and quartz glass basic sensor discontinued on May 25th, 2024! |
Discontinued on May 25th, 2024! Contact us for existing stocks or alternatives, our team will be happy to support you.
Documents for download:
More pictures of the product:
Changes to the specifications by the manufacturer are possible without prior notice. Please contact us if needed or interested. We also advise you on the suitability of the product for a particular application and provide you with an individual price quote.
Last update: 06.13.2023
