Description | Xenon Zirconia Lens by Schneider Kreuznach |
Articlenumber (Eureca): | 06.05.0176 |
Origin: | Germany |
Manufacturer: | Schneider Kreuznach |
Designation | ZIRCONIA 0.03/0.2x V48 |
Old Designation | Xenon-Zirconia 3.3/92 |
Model Series | ZIRCONIA |
Type | standard |
Version | –0011 |
Manufacturer ID | 1073622 |
Mount | V48-Mount |
Focal length | 92 mm |
Aperture | 3.3–11 |
max. Sensor Format | 62.5 mm |
max. Angle | 32 ° |
Magnification | −0.20 (−0.24 – −0.16) × |
Min. free working distance [mm] | 429–620 mm |
Filter thread [mm] | M46 × 0.75 |
Dimension [mm] | 55 × 63 |
Weight | 246 g |
This lens is designed for 12 k / 5 µm line scan sensors, but can also be used in many applications with area sensors up to 67 mm diagonal. Optimized for a specific magnification of 0.2×, the lens offers high performance in a small and compact package. The universal V48 mount enables the best azimuth adjustment and the installation of accessories such as focus mounts, extension sleeves and camera adapters.
Key features:
Applications:
For full details and specifications, please refer to the data sheet linked below.
Documents for download:
Other versions of the article and matching products:
Changes to the specifications by the manufacturer are possible without prior notice. Please contact us if needed or interested. We also advise you on the suitability of the product for a particular application and provide you with an individual price quote.
Last update: 11.11.2022
