DescriptionLens by Kowa
Articlenumber (Eureca):06.17.0079
Origin: Japan
Manufacturer: Kowa
Focal length16 mm
Pixel size3.5 µm
Iris ControlManual
Design WavelengthVIS 380–780; IR-corrected (Day & Night) nm
Focus range [m]0.3–∞ m
Focus ControlManual
Shooting range at MOD, horizontal171.4 mm
Shooting range at MOD, vertical127.4 mm
Distortion−0.8 %
Backfocus [mm]14.7 mm
Filter threadM27 × P0.5
Dimension [mm]Ø34 × 44.5
Weight100 g
Operating Temperature−10 °C – +50 °C

To the product series

  • Up to 5 Megapixel
  • Metal mount
  • IR-corrected
  • Metal housing
  • Application: ITS/traffic monitoring

Documents for download:


Other versions of the article and matching products:

  • LM25JC5M-IR: same series, next larger focal length (25 mm)

Changes to the specifications by the manufacturer are possible without prior notice. Please contact us if needed or interested. We also advise you on the suitability of the product for a particular application and provide you with an individual price quote.

Last update: 01.12.2021
